KIT INCLUDES
Base station transmitter
AC adapter for transmitter
(3) Rechargeable, multifunction collars
Short hair collar probes
Long hair collar probes
Collar charger
AC adapter for charger
500 ft. Ultra-wire
4 wire splices
Mounting hardware
RX-10 Multi-Function Collar:
Weight (less strap): 1.5 oz
Stimulus output: Proportionally
Progressive AC Stimulus Plus 86 dB
Sound Stimulus
Waterproof housing: submersible to 5 ft.
Battery: internal rechargeable lithium ion
Ultrasonic output: 40 kHz coded
ultrasound at 100 dB
Ultrasonic range: up to 30 ft.
built-in test button and LED indicator for stimulus verification and battery level
X-10 Base Station Transmitter:
Radio output: 14 kHz Coded Digital RF
Output Signal (eliminates false triggers from environmental radio waves)
Working range: up to 50 acres (requires purchase of additional wire)
Field width: adjustable from 0 ft. up to 18 ft.
System status panel: illuminated panel indicates overall system condition, battery level, loop continuity and operating mode
Alarms: audible wire break alarm, visual indicator on system status panel
Waterproof housing: continuous seal for outdoor use
Terminals: quick connect wire terminals; push button disconnect
AC adapter: 110 vac input, 14 vac output @ 500 mA
Internal battery: optional rechargeable back-up battery (sold separately), 12 volts @ 0.8 mAH - internal circuitry automatically recharges battery
Ultra Wire:
Core diameter: 0.035""
Overall diameter: 0.10"
Pull strength: 80 lb. test
Ratings: UV resistant, moisture resistant, corrosion resistant, rot resistant, burial grade
UPC: 032868100134
